Automation describes a wide range of technologies that reduce human intervention in processes, mainly by predetermining decision criteria, subprocess relationships, and related actions, as well as embodying those predeterminations in machines.[1][2] Automation has been achieved by various means including mechanical, hydraulic, pneumatic, electrical, electronic devices, and computers, usually in combination. Complicated systems, such as modern factories, airplanes, and ships typically use combinations of all of these techniques. The benefit of automation includes labor savings, reducing waste, savings in electricity costs, savings in material costs, and improvements to quality, accuracy, and precision.

Automation includes the use of various equipment and control systems such as machinery, processes in factories, boilers,[3] and heat-treating ovens, switching on telephone networks, steering, stabilization of ships, aircraft and other applications and vehicles with reduced human intervention.[4] Examples range from a household thermostat controlling a boiler to a large industrial control system with tens of thousands of input measurements and output control signals. Automation has also found a home in the banking industry. It can range from simple on-off control to multi-variable high-level algorithms in terms of control complexity.

In the simplest type of an automatic control loop, a controller compares a measured value of a process with a desired set value and processes the resulting error signal to change some input to the process, in such a way that the process stays at its set point despite disturbances. This closed-loop control is an application of negative feedback to a system. The mathematical basis of control theory was begun in the 18th century and advanced rapidly in the 20th. The term automation, inspired by the earlier word automatic (coming from automaton), was not widely used before 1947, when Ford established an automation department.[5] It was during this time that the industry was rapidly adopting feedback controllers, which were introduced in the 1930s.[6]

The World Bank's World Development Report of 2019 shows evidence that the new industries and jobs in the technology sector outweigh the economic effects of workers being displaced by automation.[7] Job losses and downward mobility blamed on automation have been cited as one of many factors in the resurgence of nationalist, protectionist and populist politics in the US, UK and France, among other countries since the 2010s.[8][9][10][11][12]

History

Ctesibius's clepsydra (3rd century BC)

It was a preoccupation of the Greeks and Arabs (in the period between about 300 BC and about 1200 AD) to keep accurate track of time. In Ptolemaic Egypt, about 270 BC, Ctesibius described a float regulator for a water clock, a device not unlike the ball and cock in a modern flush toilet. This was the earliest feedback-controlled mechanism.[13] The appearance of the mechanical clock in the 14th century made the water clock and its feedback control system obsolete.

The Persian Banū Mūsā brothers, in their Book of Ingenious Devices (850 AD), described a number of automatic controls.[14] Two-step level controls for fluids, a form of discontinuous variable structure controls, were developed by the Banu Musa brothers.[15] They also described a feedback controller.[16][17] The design of feedback control systems up through the Industrial Revolution was by trial-and-error, together with a great deal of engineering intuition. It was not until the mid-19th century that the stability of feedback control systems was analyzed using mathematics, the formal language of automatic control theory.[citation needed]

The centrifugal governor was invented by Christiaan Huygens in the seventeenth century, and used to adjust the gap between millstones.[18][19][20]

Industrial Revolution in Western Europe

Steam engines promoted automation through the need to control engine speed and power.

The introduction of prime movers, or self-driven machines advanced grain mills, furnaces, boilers, and the steam engine created a new requirement for automatic control systems including temperature regulators (invented in 1624; see Cornelius Drebbel), pressure regulators (1681), float regulators (1700) and speed control devices. Another control mechanism was used to tent the sails of windmills. It was patented by Edmund Lee in 1745.[21] Also in 1745, Jacques de Vaucanson invented the first automated loom. Around 1800, Joseph Marie Jacquard created a punch-card system to program looms.[22]

In 1771 Richard Arkwright invented the first fully automated spinning mill driven by water power, known at the time as the water frame.[23] An automatic flour mill was developed by Oliver Evans in 1785, making it the first completely automated industrial process.[24][25]

A flyball governor is an early example of a feedback control system. An increase in speed would make the counterweights move outward, sliding a linkage that tended to close the valve supplying steam, and so slowing the engine.

A centrifugal governor was used by Mr. Bunce of England in 1784 as part of a model steam crane.[26][27] The centrifugal governor was adopted by James Watt for use on a steam engine in 1788 after Watt's partner Boulton saw one at a flour mill Boulton & Watt were building.[21] The governor could not actually hold a set speed; the engine would assume a new constant speed in response to load changes. The governor was able to handle smaller variations such as those caused by fluctuating heat load to the boiler. Also, there was a tendency for oscillation whenever there was a speed change. As a consequence, engines equipped with this governor were not suitable for operations requiring constant speed, such as cotton spinning.[21]

Several improvements to the governor, plus improvements to valve cut-off timing on the steam engine, made the engine suitable for most industrial uses before the end of the 19th century. Advances in the steam engine stayed well ahead of science, both thermodynamics and control theory.[21] The governor received relatively little scientific attention until James Clerk Maxwell published a paper that established the beginning of a theoretical basis for understanding control theory.

20th century

Relay logic was introduced with factory electrification, which underwent rapid adaption from 1900 through the 1920s. Central electric power stations were also undergoing rapid growth and the operation of new high-pressure boilers, steam turbines and electrical substations created a large demand for instruments and controls. Central control rooms became common in the 1920s, but as late as the early 1930s, most process controls were on-off. Operators typically monitored charts drawn by recorders that plotted data from instruments. To make corrections, operators manually opened or closed valves or turned switches on or off. Control rooms also used color-coded lights to send signals to workers in the plant to manually make certain changes.[28]

The development of the electronic amplifier during the 1920s, which was important for long-distance telephony, required a higher signal-to-noise ratio, which was solved by negative feedback noise cancellation. This and other telephony applications contributed to the control theory. In the 1940s and 1950s, German mathematician Irmgard Flügge-Lotz developed the theory of discontinuous automatic controls, which found military applications during the Second World War to fire control systems and aircraft navigation systems.[6]

Controllers, which were able to make calculated changes in response to deviations from a set point rather than on-off control, began being introduced in the 1930s. Controllers allowed manufacturing to continue showing productivity gains to offset the declining influence of factory electrification.[29]

Factory productivity was greatly increased by electrification in the 1920s. U.S. manufacturing productivity growth fell from 5.2%/yr 1919–29 to 2.76%/yr 1929–41. Alexander Field notes that spending on non-medical instruments increased significantly from 1929 to 1933 and remained strong thereafter.[29]

The First and Second World Wars saw major advancements in the field of mass communication and signal processing. Other key advances in automatic controls include differential equations, stability theory and system theory (1938), frequency domain analysis (1940), ship control (1950), and stochastic analysis (1941).

Starting in 1958, various systems based on solid-state[30][31] digital logic modules for hard-wired programmed logic controllers (the predecessors of programmable logic controllers [PLC]) emerged to replace electro-mechanical relay logic in industrial control systems for process control and automation, including early Telefunken/AEG Logistat, Siemens Simatic, Philips/Mullard/Valvo [de] Norbit, BBC Sigmatronic, ACEC Logacec, Akkord [de] Estacord, Krone Mibakron, Bistat, Datapac, Norlog, SSR, or Procontic systems.[30][32][33][34][35][36]

In 1959 Texaco's Port Arthur Refinery became the first chemical plant to use digital control.[37] Conversion of factories to digital control began to spread rapidly in the 1970s as the price of computer hardware fell.

Significant applications

The automatic telephone switchboard was introduced in 1892 along with dial telephones. By 1929, 31.9% of the Bell system was automatic.[38]: 158  Automatic telephone switching originally used vacuum tube amplifiers and electro-mechanical switches, which consumed a large amount of electricity. Call volume eventually grew so fast that it was feared the telephone system would consume all electricity production, prompting Bell Labs to begin research on the transistor.[39]

The logic performed by telephone switching relays was the inspiration for the digital computer. The first commercially successful glass bottle-blowing machine was an automatic model introduced in 1905.[40] The machine, operated by a two-man crew working 12-hour shifts, could produce 17,280 bottles in 24 hours, compared to 2,880 bottles made by a crew of six men and boys working in a shop for a day. The cost of making bottles by machine was 10 to 12 cents per gross compared to $1.80 per gross by the manual glassblowers and helpers.

Sectional electric drives were developed using control theory. Sectional electric drives are used on different sections of a machine where a precise differential must be maintained between the sections. In steel rolling, the metal elongates as it passes through pairs of rollers, which must run at successively faster speeds. In paper making paper, the sheet shrinks as it passes around steam-heated drying arranged in groups, which must run at successively slower speeds. The first application of a sectional electric drive was on a paper machine in 1919.[41] One of the most important developments in the steel industry during the 20th century was continuous wide strip rolling, developed by Armco in 1928.[42]

Automated pharmacology production

Before automation, many chemicals were made in batches. In 1930, with the widespread use of instruments and the emerging use of controllers, the founder of Dow Chemical Co. was advocating continuous production.[43]

Self-acting machine tools that displaced hand dexterity so they could be operated by boys and unskilled laborers were developed by James Nasmyth in the 1840s.[44] Machine tools were automated with Numerical control (NC) using punched paper tape in the 1950s. This soon evolved into computerized numerical control (CNC).

Today extensive automation is practiced in practically every type of manufacturing and assembly process. Some of the larger processes include electrical power generation, oil refining, chemicals, steel mills, plastics, cement plants, fertilizer plants, pulp and paper mills, automobile and truck assembly, aircraft production, glass manufacturing, natural gas separation plants, food and beverage processing, canning and bottling and manufacture of various kinds of parts. Robots are especially useful in hazardous applications like automobile spray painting. Robots are also used to assemble electronic circuit boards. Automotive welding is done with robots and automatic welders are used in applications like pipelines.

Space/computer age

With the advent of the space age in 1957, controls design, particularly in the United States, turned away from the frequency-domain techniques of classical control theory and backed into the differential equation techniques of the late 19th century, which were couched in the time domain. During the 1940s and 1950s, German mathematician Irmgard Flugge-Lotz developed the theory of discontinuous automatic control, which became widely used in hysteresis control systems such as navigation systems, fire-control systems, and electronics. Through Flugge-Lotz and others, the modern era saw time-domain design for nonlinear systems (1961), navigation (1960), optimal control and estimation theory (1962), nonlinear control theory (1969), digital control and filtering theory (1974), and the personal computer (1983).

Advantages, disadvantages, and limitations

Perhaps the most cited advantage of automation in industry is that it is associated with faster production and cheaper labor costs. Another benefit could be that it replaces hard, physical, or monotonous work.[45] Additionally, tasks that take place in hazardous environments or that are otherwise beyond human capabilities can be done by machines, as machines can operate even under extreme temperatures or in atmospheres that are radioactive or toxic. They can also be maintained with simple quality checks. However, at the time being, not all tasks can be automated, and some tasks are more expensive to automate than others. Initial costs of installing the machinery in factory settings are high, and failure to maintain a system could result in the loss of the product itself.

Moreover, some studies seem to indicate that industrial automation could impose ill effects beyond operational concerns, including worker displacement due to systemic loss of employment and compounded environmental damage; however, these findings are both convoluted and controversial in nature, and could potentially be circumvented.[46]

The main advantages of automation are:

• Increased throughput or productivity
• Improved quality
• Increased predictability
• Improved robustness (consistency), of processes or product
• Increased consistency of output
• Reduced direct human labor costs and expenses
• Reduced cycle time
• Increased accuracy
• Relieving humans of monotonously repetitive work [47]
• Required work in development, deployment, maintenance, and operation of automated processes — often structured as "jobs"
• Increased human freedom to do other things

Automation primarily describes machines replacing human action, but it is also loosely associated with mechanization, machines replacing human labor. Coupled with mechanization, extending human capabilities in terms of size, strength, speed, endurance, visual range & acuity, hearing frequency & precision, electromagnetic sensing & effecting, etc., advantages include:
